Mounting Clamp (Flat Frame Type)
Click this image to zoom it.
Move the mouse over the image to zoom
Part Number
Configured Part Number is shown.
- Download
Product Details - CAD Data unavailable
| Type | Material | Surface Treatment |
| AT−FRCL | A6061 Equivalent | White Anodized Aluminum |
| Part Number |
|---|
| AT-FRCL1020-D5.5 |
| AT-FRCL1020-D5.5-BPT5 |
| AT-FRCL1020-D5.5-BPT12 |
| AT-FRCL1020-D6.6 |
| AT-FRCL1020-D6.6-BPT5 |
| AT-FRCL1020-D6.6-BPT12 |
| AT-FRCL1020-D9 |
| AT-FRCL1020-D9-BPT5 |
| AT-FRCL1020-D9-BPT12 |
| Part Number | Standard Unit Price | Minimum order quantity | Volume Discount | Days to Ship | Mounting Bolt Set | Applicable Base Plate Thickness T (mm) | Compatible Base Plate Mounting Hole Size D (φ) |
|---|---|---|---|---|---|---|---|
MYR 23.86 | 1 Piece(s) | 3 Day(s) | None | - | 5.5 | ||
MYR 25.08 | 1 Piece(s) | 3 Day(s) | Yes | 5 | 5.5 | ||
MYR 25.08 | 1 Piece(s) | 3 Day(s) | Yes | 12 | 5.5 | ||
MYR 23.86 | 1 Piece(s) | 3 Day(s) | None | - | 6.6 | ||
MYR 25.08 | 1 Piece(s) | 3 Day(s) | Yes | 5 | 6.6 | ||
MYR 25.08 | 1 Piece(s) | 3 Day(s) | Yes | 12 | 6.6 | ||
MYR 23.86 | 1 Piece(s) | 3 Day(s) | None | - | 9 | ||
MYR 25.08 | 1 Piece(s) | 3 Day(s) | Yes | 5 | 9 | ||
MYR 25.08 | 1 Piece(s) | 3 Day(s) | Yes | 12 | 9 |
Loading...
Specification Table
| Part Number | − | D | − | Mounting Bolt |
| AT−FRCL1020 | − | D5.5 | ||
| AT−FRCL1020 | − | D6.6 | − | BPT5 |
■Mounting Clamp
| Connection Frame | A | B | C | E | F | D1 | G | H | J | K | Flat Frame Fastening Bolts | Weight (g) *1 | Part Number | Mounting Hole Size D | |
| Type | No. | ||||||||||||||
| HFSFN5－1020 (Flat Frame) | 36 | 20 | 20 | 31 | 21 | 5.5 | 14 | 9 | － | 15 | M5 Length 14 (Accessory) | 25 | AT－FRCL | 1020 | 5.5 |
| 38 | 20 | 32 | － | 25 | 6.6 | ||||||||||
| 40 | 24 | 32.5 | 12 | 27 | 9 | ||||||||||
*1 The weight is an approximate value. Consider it only as a guideline.
Check with WOS for quantities over display.
■Mounting Clamp (Mounting Bolt Set Product)
| Part Number | Mounting Hole Size D | Mounting Bolt | |
| Type | No. | ||
| AT－FRCL | 1020 | 5.5 | BPT5 BPT12 |
| 6.6 | |||
| 9 | |||
Check with WOS for quantities over display.
■Bolt Set Product Details
| Mounting Clamp Part Number (Bolt Set Product) | Applicable Base Plate (AT－BPL) Thickness T | Mounting Bolt Details |
| AT－FRCL1020－D5.5－BPT5 | 5 (AT－BPL□□－T5) | M5×P0.8－25(CB5－25): 1 pc |
| AT－FRCL1020－D6.6－BPT5 | M6×P1.0－25(CB6－25): 1 pc | |
| AT－FRCL1020－D9－BPT5 | M8×P1.25－25(CB8－25): 2 pc | |
| AT－FRCL1020－D5.5－BPT12 | 12 (AT－BPL□□－T12) | M5×P0.8－30(CB5－30): 1 pc |
| AT－FRCL1020－D6.6－BPT12 | M6×P1.0－30(CB6－30): 1 pc | |
| AT－FRCL1020－D9－BPT12 | M8×P1.25－30(CB8－30): 2pc |
Usage Example
Basic Information
| Connection Frame | Flat Frame | Compatible Base Plate Mounting Hole Size D1 (φ) | 5.5 |
|---|
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
