SS3FUR, UL-Standard, Small-Diameter
Click this image to zoom it.
Move the mouse over the image to zoom
- Volume Discount
300 V UL Small Diameter Mobile Signals Cable
- VW-1
- ULAWM
- Oil-Resistant
- Strand Wire
- Thinned Wire Conductor
- 300 V
● Uses pliable and sleek urethane sheath.
· This product is compatible with "UL Traceability Program / Processed Wire."
* For cables in stock, please keep in mind that because we cut them to the specified size, they cannot be canceled or returned.
* All unit prices are per meter.
Unit Price Calculation Method
[Formula: Last digits of model number (m) x unit price per meter above]
* Color and softness may vary slightly due to manufacturer changes.
Electrical Appliance and Material Safety Law certificate has not been obtained.
Part Number
Configured Part Number is shown.
Specifications
| Sales Unit | |||
| Model Number | AWG Size | Number of Cores | Total Length *3 or Specified Length |
| SS3FUR | 26 | 2 | 1 ~ 100 (Specify 1 m Increment) / 500 / 1000 |
| 3 | |||
| 4 | |||
| 6 | |||
| 10 | |||
| 24 | 2 | ||
| 3 | |||
| 4 | |||
| 6 | |||
| 8 | |||
| 10 | |||
| 12 | |||
| 22 | 2 | ||
| 4 | |||
| 6 | |||
| 8 | |||
| 10 | |||
| 12 |
Be sure to read the following precautions when you place an order.
*Length in "m" is included in our model numbers. Always specify quantity as number of units, not as meters.
*1 Stock products are indicated with T or A in the price column at right.
*2 All unit prices above are per meter.
Unit Price Calculation Method [Formula: Last digits of model number (m) x unit price per meter above]
*3 Please note that when ordering 1000 m and 500 m, the order will be delivered as 100 m windings (we cannot accept orders for single cables).
More Information
Specifications
| Model Number | AWG Size | Number of Cores | Estimated Section Area (mm2) *1 | Twisted Structure (See Figure) | Number of Wire Cores | Finished *4 Outer Diameter (mm) | Approximate Mass kg/km | Electrical Properties | Conductor | Insulation | Wire Core Outer Diameter Approx. (mm) | Sheath | Specification | Sample Provided | |||||||
| Allowable Current A (30 °C) *2 | Conductor Resistance Ω / km (20 °C) | Insulation Properties MΩkm (20 °C) | Withstand Voltage V / 5 min | Structure Strands / mm | Outer Diameter Approx. (mm) | Plating *3 | Thickness (mm) | Material *3 | Thickness (mm) | Material *3 | |||||||||||
| SS3FUR | 26 | 2 | 0.12 | Core / Layer Stranding | 2 | 3.7 | 17 | 2.4 | 128 | 1500 | 2000 | 7/10/0.05 | 0.54 | Tin | 0.15 | ETFE | 0.84 | 0.9 | Urethane | AWM cUL20936 | ◎ |
| 3 | 3 | 3.9 | 20 | 2.4 | ◎ | ||||||||||||||||
| 4 | 4 | 4.1 | 24 | 2.1 | ◎ | ||||||||||||||||
| 6 | 6 | 4.6 | 31 | 1.8 | ◎ | ||||||||||||||||
| 10 | 10 | 5.6 | 47 | 1.5 | ◎ | ||||||||||||||||
| 24 | 2 | 0.2 | 2 | 4 | 22 | 3.2 | 85.7 | 7/15/0.05 | 0.7 | 1.00 | ◎ | ||||||||||
| 3 | 3 | 4.2 | 26 | 3.2 | ◎ | ||||||||||||||||
| 4 | 4 | 4.5 | 30 | 2.8 | ◎ | ||||||||||||||||
| 6 | 6 | 5 | 40 | 2.4 | ◎ | ||||||||||||||||
| 8 | 8 | 5.7 | 52 | 2.1 | ◎ | ||||||||||||||||
| 10 | 10 | 6.3 | 63 | 2.1 | ◎ | ||||||||||||||||
| 12 | 12 | 6.9 | 76 | 2.1 | ◎ | ||||||||||||||||
| 22 | 2 | 0.3 | 2 | 4.4 | 28 | 4.4 | 53.5 | 7/24/0.05 | 0.9 | 1.20 | ◎ | ||||||||||
| 4 | 4 | 5 | 40 | 3.9 | ◎ | ||||||||||||||||
| 6 | 6 | 5.6 | 55 | 3.4 | ◎ | ||||||||||||||||
| 8 | 8 | 6.4 | 72 | 2.9 | ◎ | ||||||||||||||||
| 10 | 10 | 7.1 | 89 | 2.9 | ◎ | ||||||||||||||||
| 12 | 12 | 7.9 | 107 | 2.9 | ◎ | ||||||||||||||||
*1 The size conversion is for reference only. Refer to the comparison table on >>Click here for details.
*2 The value of allowable current is to be used only as a reference value and is not guaranteed.
*3 How to View Materials
[Plating] Tin... Tin Plated Annealed Copper Wire
[Materials] PVC... Polyvinyl Chloride; PE... Polyethylene-based Material;
P... Polyester-based Material; Fluorine... Various Fluorine Resins; *... Other
*4 For the outer diameter size of cables, wire sheath (coat), etc., refer to "Finished Outer Diameter" in the table above.
Current Reduction Factor
| Ambient Temperature (°C) | 30 | 40 | 50 | 60 | 70 | 80 |
| Current Reduction Factor | 1.00 | 0.90 | 0.82 | 0.74 | 0.66 | 0.56 |
(Example) Allowable current value 2.4 x 0.9 = 2.16 (A) when the ambient temperature for 2-core AWG26 is 40 °C
| Part Number | Standard Unit Price | Minimum order quantity | Volume Discount | Days to Ship | Overall Length (m) | Conductor Cross Section (mm2) | AWG size (AWG) | Number Of Cores (Core) | Finished outer diameter (mm) | Grounding Wire |
|---|---|---|---|---|---|---|---|---|---|---|
MYR 2,953.24 | 1 Piece(s) | 2 Day(s) or more | 90 | 0.3 | 22 | 2 | 4.4 | - | ||
MYR 895.99 | 1 Piece(s) | 2 Day(s) or more | 18 | 0.3 | 22 | 4 | 5 | GY (green/yellow) colored | ||
MYR 1,775.16 | 1 Piece(s) | 2 Day(s) or more | 36 | 0.3 | 22 | 4 | 5 | GY (green/yellow) colored | ||
MYR 2,410.12 | 1 Piece(s) | 2 Day(s) or more | 49 | 0.3 | 22 | 4 | 5 | GY (green/yellow) colored | ||
MYR 3,191.63 | 1 Piece(s) | 2 Day(s) or more | 65 | 0.3 | 22 | 4 | 5 | GY (green/yellow) colored | ||
MYR 3,856.55 | 1 Piece(s) | 2 Day(s) or more | 53 | 0.3 | 22 | 6 | 5.6 | GY (green/yellow) colored | ||
MYR 749.00 | 1 Piece(s) | 2 Day(s) or more | 7 | 0.3 | 22 | 10 | 7.1 | GY (green/yellow) colored | ||
MYR 1,751.24 | 1 Piece(s) | 2 Day(s) or more | 17 | 0.3 | 22 | 10 | 7.1 | GY (green/yellow) colored | ||
MYR 1,853.25 | 1 Piece(s) | 2 Day(s) or more | 18 | 0.3 | 22 | 10 | 7.1 | GY (green/yellow) colored | ||
MYR 2,057.31 | 1 Piece(s) | 2 Day(s) or more | 20 | 0.3 | 22 | 10 | 7.1 | GY (green/yellow) colored | ||
MYR 787.52 | 1 Piece(s) | 2 Day(s) or more | 6 | 0.3 | 22 | 12 | 7.9 | GY (green/yellow) colored | ||
MYR 1,905.81 | 1 Piece(s) | 2 Day(s) or more | 15 | 0.3 | 22 | 12 | 7.9 | GY (green/yellow) colored | ||
MYR 2,157.68 | 1 Piece(s) | 2 Day(s) or more | 17 | 0.3 | 22 | 12 | 7.9 | GY (green/yellow) colored | ||
MYR 3,417.01 | 1 Piece(s) | 2 Day(s) or more | 27 | 0.3 | 22 | 12 | 7.9 | GY (green/yellow) colored | ||
MYR 8,706.22 | 1 Piece(s) | 2 Day(s) or more | 69 | 0.3 | 22 | 12 | 7.9 | GY (green/yellow) colored | ||
MYR 10,469.30 | 1 Piece(s) | 2 Day(s) or more | 83 | 0.3 | 22 | 12 | 7.9 | GY (green/yellow) colored | ||
MYR 12,232.36 | 1 Piece(s) | 2 Day(s) or more | 97 | 0.3 | 22 | 12 | 7.9 | GY (green/yellow) colored | ||
MYR 252.21 | 1 Piece(s) | 2 Day(s) or more | 9 | 0.2 | 24 | 2 | 4 | - | ||
MYR 266.61 | 1 Piece(s) | 2 Day(s) or more | 11 | 0.2 | 24 | 2 | 4 | - | ||
MYR 1,913.66 | 1 Piece(s) | 2 Day(s) or more | 47 | 0.2 | 24 | 3 | 4.2 | GY (green/yellow) colored | ||
MYR 2,115.44 | 1 Piece(s) | 2 Day(s) or more | 52 | 0.2 | 24 | 3 | 4.2 | GY (green/yellow) colored | ||
MYR 2,841.91 | 1 Piece(s) | 2 Day(s) or more | 70 | 0.2 | 24 | 3 | 4.2 | GY (green/yellow) colored | ||
MYR 2,962.99 | 1 Piece(s) | 2 Day(s) or more | 73 | 0.2 | 24 | 3 | 4.2 | GY (green/yellow) colored | ||
MYR 3,430.78 | 1 Piece(s) | Available | 2 Day(s) or more | 100 | 0.2 | 24 | 3 | 4.2 | GY (green/yellow) colored | |
MYR 2,044.90 | 1 Piece(s) | 2 Day(s) or more | 50 | 0.2 | 24 | 4 | 4.5 | GY (green/yellow) colored | ||
MYR 3,397.54 | 1 Piece(s) | 2 Day(s) or more | 81 | 0.2 | 24 | 4 | 4.5 | GY (green/yellow) colored | ||
MYR 161.13 | 1 Piece(s) | 2 Day(s) or more | 2 | 0.2 | 24 | 8 | 5.7 | GY (green/yellow) colored | ||
MYR 1,460.09 | 1 Piece(s) | 2 Day(s) or more | 20 | 0.2 | 24 | 8 | 5.7 | GY (green/yellow) colored | ||
MYR 2,154.93 | 1 Piece(s) | 2 Day(s) or more | 20 | 0.2 | 24 | 12 | 6.9 | GY (green/yellow) colored | ||
MYR 1,341.02 | 1 Piece(s) | 2 Day(s) or more | 52 | 0.12 | 26 | 3 | 3.9 | GY (green/yellow) colored | ||
MYR 1,547.35 | 1 Piece(s) | 2 Day(s) or more | 42 | 0.12 | 26 | 4 | 4.1 | GY (green/yellow) colored | ||
MYR 2,166.85 | 1 Piece(s) | 2 Day(s) or more | 59 | 0.12 | 26 | 4 | 4.1 | GY (green/yellow) colored | ||
MYR 1,280.95 | 1 Piece(s) | 2 Day(s) or more | 16 | 0.12 | 26 | 10 | 5.6 | GY (green/yellow) colored | ||
MYR 1,596.99 | 1 Piece(s) | 2 Day(s) or more | 20 | 0.12 | 26 | 10 | 5.6 | GY (green/yellow) colored | ||
MYR 3,572.22 | 1 Piece(s) | 2 Day(s) or more | 45 | 0.12 | 26 | 10 | 5.6 | GY (green/yellow) colored |
Loading...
Basic Information
| Rated Voltage | 300V | Shield | None | Properties | Oil resistance / Abrasion resistance |
|---|---|---|---|---|---|
| Representative Standard | UL / CSA(c-UL) | Sheath (outer coating) color | Black | Sheath (outer coating) material | Urethane based |
| Insulation body materials | Fluorine | Power supply/signal | For signals | Other properties | Elastic, Vibration-resistant, Pliable, Flexible, Carrier-tested Cable |
Specification/Dimensions
-
Overall Length(m)
-
Conductor Cross Section(mm2)
-
AWG size(AWG)
-
Number Of Cores(Core)
-
Finished outer diameter(mm)
-
Grounding Wire
- GY (green/yellow) colored
Days to Ship
-
- All
- 2 Day(s) or Less
Specify Alterations
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
Additional Products in this Category
- SS300R, UL-Standard, Small-Diameter
- SS300RSB, UL-Standard, Small-Diameter Shield
- MRC3SB UL Standard with Shield
- NA3PEURP (SB) Very Highly Flexible UL Standard
- UL2464FASB UL Standard with Shield
- EXTTYPE2 30 V UL Standard
- VCTF23NXS UL / PSE Supported with Shield
- Chain Flex CF5- Control Cable
Customers Who Viewed This Item Also Viewed
-
-
Slim Type Highly Flexible Robot Cable ORP-SL SeriesOKI ELECTRIC CABLE
Standard Price : MYR 590.45-
Days to Ship : 4 Day(s) or more
-
SS300R, UL-Standard, Small-Diameter
MISUMI_Test
Standard Price : MYR 25.98-
Days to Ship : 2 Day(s) or more
-
-
SSCL3R, UL-Listed (CL3) Support
MISUMI_Test
Standard Price : MYR 53.04-
Days to Ship : 2 Day(s) or more
-
NA3HR, Small-Diameter, Highly Flexible UL-Standard
MISUMI_Test
Standard Price : MYR 49.98-
Days to Ship : 2 Day(s) or more
-
-
-
MASW-AS3KK UL Compatible Cable
MISUMI_Test
Standard Price : MYR 122.28-
Days to Ship : 2 Day(s) or more
-
RMFEV(CL3) NFPA79 Compliant Robot CableDYDEN
Standard Price : MYR 324.31-
Days to Ship : 2 Day(s) or more
-
-
D-LIST3Z Cable for Flexing ApplicationsDYDEN
Standard Price : MYR 427.11-
Days to Ship : 2 Day(s) or more
Tech Support
- Factory Automation, Electronics, Tools, & MRO (Maintenance, Repair and Operations)
- Tel：(60) 3 7960 8499 / FAX：(60) 3 7960 7499
- 9:00am - 6:00pm (Monday - Friday)
9:00am - 1:00pm (Saturday) - Technical Inquiry
- Credit Card
- Bank Transfer
Social Media
MISUMI Contact
Copyright © MISUMI Corporation All Rights Reserved.
How can we improve?
How can we improve?
While we are not able to respond directly to comments submitted in this form, the information will be reviewed for future improvement.
Customer Privacy Policy
Thank you for your cooperation.
While we are not able to respond directly to comments submitted in this form, the information will be reviewed for future improvement.
Please use the inquiry form.
Customer Privacy Policy
