Mini-DIN Cable Molded Connector/Panel Mountable Connector
- Volume Discount
Sino-Japanese Common Model Used MINIDIN Connector Harness
- RS232
This is a mini DIN free length harness
● A harness that uses mini DIN connectors widely used in personal computers and FA equipment / measuring devices.
Along with the assembly type using cable with excellent flexibility, 3 types including an integrated mold type and flange equipped and panel-mountable types are also available.
· HWMDH and HMDH cannot be specified as options.
· HMDH does not have an 8-core specification for D cables.
· The appearance and specifications are subject to change without notice.
· Shield is connected and treated in the hood.
Wiring and Wire Color Page >> Click here
Component Page >> Click here
Part Number
Configured Part Number is shown.
Specifications
| Connector model | Shape Specification model | Outline Image Drawing | Cable model | Number of Cores | Specified Length (m) |
| P (Male) |  |   | 4 | 0.2 – 30 0.1 m It can be specified by 0.1 m increments | |
| 5 | |||||
| 6 | |||||
| 8 | |||||
| S (Female) |  | 4 | |||
| 5 | |||||
| 6 | |||||
| 8 | |||||
| MDH | PP (Male / Male) |  | 4 | ||
| 5 | |||||
| 6 | |||||
| 8 | |||||
| PS (Male / Female) |  | 4 | |||
| 5 | |||||
| 6 | |||||
| Connector | 8 | ||||
| SS (Female / Female) |  | 4 | |||
| 5 | |||||
| 6 | |||||
| 8 |
| Connector model | Shape Specification model | Outline Image Drawing | Cable model | Number of Cores | Total Length (m) |
| TWMDH (Molded model Mini DIN Connector Cream Color) | P (Male) |  |  | 6 | 2 3 4 |
| 8 | |||||
| PS (Male / Female) |  | 6 | |||
| 8 | |||||
| RMDH Panel Mount (Molded model Mini DIN Connector Cream Color) | S (Female) |  |  | 6 | 0.5 1 2 |
| SP (Female / Male) |  | 0.5 1 2 5 |
| Connector model | Shape Specification model | Outline Image Drawing | Cable model | Number of Cores | Total Length (m) |
| HWMDH (Molded model Mini DIN Connector Cream Color) | P (Male) | | | 6 | 2 3 4 7 10 15 |
| 8 | |||||
| PS (Male / Female) | | 8 | 2 3 4 | ||
| HMDH Panel Mount (Molded model Mini DIN Connector Cream Color) | S (Female) | | | 6 | 0.5 1 2 |
| SP (Female / Male) | | 0.5 1 2 |
More Information
| Specified Length (m) | – 0.9 | 1 – 4 | 4.1 – 50 |
| Tolerance | +20 mm | +50 mm | + 3% of Specified Length |
| Part Number |
|---|
| HWMDH-P-B-6-7 |
| HWMDH-PS-B-8-2 |
| Part Number | Standard Unit Price | Minimum order quantity | Volume Discount | Days to Ship | CN2 | Number Of Cores | Length (m) | Conductor dimensions (AWG) |
|---|---|---|---|---|---|---|---|---|
MYR 150.51 | 1 Piece(s) | Available | 2 Day(s) or more | Cut off | [6] 6 | 7 | 26 | |
MYR 222.40 | 1 Piece(s) | Available | 2 Day(s) or more | Female straight | 8 | 2 | 28 |
Loading...
Basic Information
| Connector type | Mini-DIN | Connector manufacturer | Misumi | CN1 | Male straight |
|---|---|---|---|---|---|
| Cable rated voltage(V) | 300 | Cable shape | Circular | Shield | 1 Layer |
| Cable standard (UL/CSA) | UL | Cable color | Cream | Environment resistant | N/A |
| Bend tolerant | N/A | Other specifications | Mold | Cable type | B |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
