MRC3 UL Standard
Click this image to zoom it.
Move the mouse over the image to zoom
300 V UL Standard Mobile Power Supply Cable
- CSA
- VW-1
- ULAWM
- Oil-Resistant
- Strand Wire
- Thinned Wire Conductor
- 300 V
·This product is compatible with "UL Traceability Program / Processed Wire". (c-UL is not compatible)
Electrical Appliance and Material Safety Law certificate is not obtained.
Part Number
Configured Part Number is shown.
Specifications
| Model | AWG Size | Number of Cores *4 |
| MRC3 | 20 | 2 |
| 3 | ||
| 4 | ||
| 6 | ||
| 8 | ||
| 10 | ||
| 12 | ||
| 20 | ||
| 18 | 2 | |
| 3 | ||
| 4 | ||
| 6 | ||
| 8 | ||
| 10 | ||
| 12 | ||
| 20 | ||
| 16 | 2 | |
| 3 | ||
| 4 | ||
| 6 | ||
| 8 | ||
| 10 | ||
| 12 | ||
| 20 |
Be sure to read the following precautions when you place an order.
* Length in "m" is included in our part numbers. Always specify quantity as number of units, not as meters.
*2 All unit prices above are per meter.
Unit Price Calculation Method [Formula: Last digits of part number (m) x unit price per meter above]
*4 Check the indications for number of cores, pair number, core / pair number, and pair number / core when ordering (check the Specification Table for number of wire cores). 1P (1 PS) is "x 2-core".
More Information
Specifications
| Model | AWG Size | Number of Cores *1 | Estimated Section Area (mm2) *2 | Twisted Structure (See Figure) | Number of Wire Cores | Finished Outer Diameter (mm) | Approximate Mass kg/km | Electrical Properties | Conductor | Insulation | Wire Core Outer Diameter Approx. (mm) | Sheath | Specification | Sample Provided | |||||||
| Allowable Current A (30°C) *3 | Conductor Resistance Ω / km (20°C) | Insulation Properties MΩkm (20°C) | Withstand Voltage V / Min | Structure Strands / mm | Outer Diameter Approx. (mm) | Plating *4 | Thickness (mm) | Material *4 | Thickness (mm) | Material *4 | |||||||||||
| MRC3 | 20 | 2 | 0.5 | Core / Layer Stranding | 2 | 6.1 | 46 | 7.3 | 40.6 or less | 10 or more | 2000 | 6/18/0.08 | 1.1 | N/A | 0.45 | PVC | 2 | 1.0 | PVC | ULAWM 2464 CSA | - |
| 3 | 3 | 6.4 | 55 | 5.7 | - | ||||||||||||||||
| 4 | 4 | 6.9 | 67 | 5.7 | - | ||||||||||||||||
| 6 | 6 | 8.1 | 91 | 4.9 | - | ||||||||||||||||
| 8 | 8 | 9.3 | 119 | 4.1 | - | ||||||||||||||||
| 10 | 10 | 10.1 | 140 | 4.1 | - | ||||||||||||||||
| 12 | 12 | 10.4 | 158 | 3.2 | - | ||||||||||||||||
| 20 | 20 | 12.7 | 246 | 3.2 | - | ||||||||||||||||
| 18 | 2 | 0.75 | 2 | 6.5 | 55 | 9.8 | 26.1 or less | 10 or more | 2000 | 6/28/0.08 | 1.3 | 0.45 | 2.2 | 1.0 | - | ||||||
| 3 | 3 | 6.8 | 71 | 8.2 | - | ||||||||||||||||
| 4 | 4 | 7.4 | 85 | 7.3 | - | ||||||||||||||||
| 6 | 6 | 8.7 | 117 | 6.5 | - | ||||||||||||||||
| 8 | 8 | 10.0 | 154 | 5.7 | - | ||||||||||||||||
| 10 | 10 | 10.9 | 181 | 5.7 | - | ||||||||||||||||
| 12 | 12 | 11.2 | 209 | 4.9 | - | ||||||||||||||||
| 20 | 20 | 14.0 | 333 | 4.1 | 1.1 | - | |||||||||||||||
| 16 | 2 | 1.25 | 2 | 7.3 | 73 | 11 | 16.6 or less | 10 or more | 2000 | 6/44/0.08 | 1.7 | 0.45 | 2.6 | 1.0 | - | ||||||
| 3 | 3 | 7.7 | 93 | 9 | - | ||||||||||||||||
| 4 | 4 | 8.4 | 117 | 8 | - | ||||||||||||||||
| 6 | 6 | 9.9 | 161 | 7 | - | ||||||||||||||||
| 8 | 8 | 11.5 | 212 | 6 | - | ||||||||||||||||
| 10 | 10 | 12.5 | 251 | 5 | - | ||||||||||||||||
| 12 | 12 | 12.9 | 291 | 5 | - | ||||||||||||||||
| 20 | 20 | 16.3 | 476 | 4 | 1.2 | - | |||||||||||||||
*1 Please note that when the indicated Core / Pair is 1P (1PS), the number of wire cores will be "x 2-core".
*2 The size conversion is for reference only. Refer to the comparison table on >>Click here for details.
*3 The value of allowable current is to be used only as a reference value and is not guaranteed.
*4 How to View Materials
[Plating] Tin... Tin Plated Annealed Copper Wire
[Materials] PVC... Polyvinyl Chloride; PE... Polyethylene-based Material;
P... Polyester-based Material; Fluorine... Various Fluorine Resins; *... Other
*5 For the outer diameter size of cables, wire sheath (coat), etc., refer to "Finished Outer Diameter" in the table above.
Current Reduction Factor
| Ambient Temperature (°C) | 30 | 40 | 50 | 60 | 70 | 80 |
| Current Reduction Factor | 1.00 | 0.91 | 0.82 | 0.71 | 0.58 | 0.41 |
If the ambient temperature is 30 °C or above, the above current reduction factor is multiplied by the allowable current.
(Example)Allowable current at AWG20 2-core when the ambient temperature is 40°C
7.3 × 0.91 = 6.643 (A)
| Part Number |
|---|
| MRC3-16-2-5 |
| MRC3-16-2-74 |
| MRC3-18-2-2 |
| MRC3-18-2-93 |
| MRC3-18-8-[1-100/1] |
| MRC3-18-10-8 |
| MRC3-18-10-71 |
| MRC3-18-10-87 |
| MRC3-18-12-[1-100/1] |
| MRC3-20-2-29 |
| MRC3-20-2-62 |
| MRC3-20-2-93 |
| MRC3-20-3-[1-100/1] |
| MRC3-20-6-[1-100/1] |
| MRC3-20-10-9 |
| MRC3-20-10-87 |
| MRC3-20-12-[1-100/1] |
| MRC3-20-20-11 |
| MRC3-20-20-72 |
| MRC3-20-20-91 |
| MRC3-20-20-95 |
| Part Number | Standard Unit Price | Minimum order quantity | Volume Discount | Days to Ship | Overall Length (m) | Conductor Cross Section (mm2) | AWG size (AWG) | Number Of Cores (Core) | Finished outer diameter (mm) | Grounding Wire |
|---|---|---|---|---|---|---|---|---|---|---|
MYR 247.62 | 1 Piece(s) | 2 Day(s) or more | 5 | 1.25 | 16 | 2 | 7.3 | - | ||
MYR 2,983.36 | 1 Piece(s) | 2 Day(s) or more | 74 | 1.25 | 16 | 2 | 7.3 | - | ||
MYR 95.16 | 1 Piece(s) | 2 Day(s) or more | 2 | 0.75 | 18 | 2 | 6.5 | - | ||
MYR 2,895.63 | 1 Piece(s) | 2 Day(s) or more | 93 | 0.75 | 18 | 2 | 6.5 | - | ||
- | 1 Piece(s) | 4 Day(s) or more | 1 ～ 100 | 0.75 | 18 | 8 | 10 | - | ||
MYR 1,792.29 | 1 Piece(s) | 2 Day(s) or more | 8 | 0.75 | 18 | 10 | 10.9 | - | ||
MYR 8,409.87 | 1 Piece(s) | 2 Day(s) or more | 71 | 0.75 | 18 | 10 | 10.9 | - | ||
MYR 10,297.47 | 1 Piece(s) | 2 Day(s) or more | 87 | 0.75 | 18 | 10 | 10.9 | - | ||
- | 1 Piece(s) | 2 Day(s) or more | 1 ～ 100 | 0.75 | 18 | 12 | 11.2 | - | ||
MYR 526.57 | 1 Piece(s) | 2 Day(s) or more | 29 | 0.5 | 20 | 2 | 6.1 | - | ||
MYR 1,087.52 | 1 Piece(s) | 2 Day(s) or more | 62 | 0.5 | 20 | 2 | 6.1 | - | ||
MYR 1,614.49 | 1 Piece(s) | 2 Day(s) or more | 93 | 0.5 | 20 | 2 | 6.1 | - | ||
- | 1 Piece(s) | 2 Day(s) or more | 1 ～ 100 | 0.5 | 20 | 3 | 6.4 | GY (green/yellow) colored | ||
- | 1 Piece(s) | 4 Day(s) or more | 1 ～ 100 | 0.5 | 20 | 6 | 8.1 | - | ||
MYR 806.16 | 1 Piece(s) | 2 Day(s) or more | 9 | 0.5 | 20 | 10 | 10.1 | - | ||
MYR 7,443.79 | 1 Piece(s) | 2 Day(s) or more | 87 | 0.5 | 20 | 10 | 10.1 | - | ||
- | 1 Piece(s) | 2 Day(s) or more | 1 ～ 100 | 0.5 | 20 | 12 | 10.4 | - | ||
MYR 1,744.75 | 1 Piece(s) | 2 Day(s) or more | 11 | 0.5 | 20 | 20 | 12.7 | - | ||
MYR 10,672.98 | 1 Piece(s) | 2 Day(s) or more | 72 | 0.5 | 20 | 20 | 12.7 | - | ||
MYR 13,480.59 | 1 Piece(s) | 2 Day(s) or more | 91 | 0.5 | 20 | 20 | 12.7 | - | ||
MYR 14,071.67 | 1 Piece(s) | 2 Day(s) or more | 95 | 0.5 | 20 | 20 | 12.7 | - |
Loading...
Basic Information
| Rated Voltage | 300V | Shield | None | Properties | Oil resistance |
|---|---|---|---|---|---|
| Representative Standard | UL / CSA(c-UL) | Sheath (outer coating) color | Black | Sheath (outer coating) material | PVC |
| Insulation body materials | PVC | Power supply/signal | Dual use | Other properties | Vibration-resistant, Flexible, Pliable, Elastic Carrier-tested Cable |
Specification/Dimensions
-
Overall Length(m)
-
Conductor Cross Section(mm2)
-
AWG size(AWG)
-
Number Of Cores(Core)
-
Finished outer diameter(mm)
-
Grounding Wire
- GY (green/yellow) colored
Days to Ship
-
- All
- 2 Day(s) or Less
- 4 Day(s) or Less
Specify Alterations
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
